Model

SGW-150C

SGB620/40T

SGB-420/30

SGD-420/30

SGW-26

SGD-320/17B

Factory Length

200 m

100 m

100 m

100 m

100 m

80 m

Delivery Value

250 tons/hour

150 tons/hour

80 tons/hour

80 tons/hour

70 tons/hour

40 tons/hour

Chain Speed

0.868 m/s

0.86 m/s

0.86 m/s

0.88 m/s

0.86 m/s

0.59 m/s

Motor

Model

DSB-75

DSB-40

JDSB-30

JDSB-30

BJQO261-40T2

DZ3B-17

Power

75 KW X2

40 KW

30 KW

30 KW

13 KW X2

17 KW

Rotate Speed

1480 RPM

1470 RPM

1470 RPM

1470 RPM

1460 RPM

1460 RPM

Voltage

380/660 V

380/660 V

380/660 V

380/660 V

380/660 V

380/660 V

Hydraulic Coupling

Model

YL-450

YOXD400S

Rated Power

75 KW

40 KW

Operating Fluid

22# Turbine Oil

22# Turbine Oil

Injection Flow

14 L

8 L

Scraper Chain

Type

Twin Outboard Chain

Twin Outboard Chain

Twin Outboard Chain

Single Center Chain

Twin Outboard Chain

Single Center Chain

Spec.

Ф18*64 mm

Ф18X64 mm

Ф14X50 mm

Ф14X50 mm

Ф14X50 mm

Ф14X50 mm

Chain Breaking Force

≥41 tons

≥35 tons

≥25 tons

≥25 tons

≥25 tons

≥25 tons

Reduction Box Rotation Ratio

1：24.44

1：24.564

1：22.24

Center Channel  L W X H

1500X630X190

1500X620X180

1200X420X150

1200X420X150

1200X420X150

1200X420X150

Machine Weight

87.6 tons

17.6 tons

10.29 tons

9.56 tons

9.2 tons

7.34 tons
